PIE 820PM Multifunction Process Calibrator

Overview PIE 820PM Multifunction Process Calibrator

The PIE 820PM Multifunction Process Calibrator is the panel-mount version of the popular PIE 820 handheld calibrator, designed for calibration benches, control panels, and built-in process simulation stations. It delivers the same powerful multifunction calibration capabilities in a fixed, panel-mounted format, while still allowing removal for annual calibration.

Compact, intuitive, and technician-friendly, the 820PM replaces multiple single-function calibrators with one reliable instrument. Its EZ-DIAL Double Click Menu enables fast setup and operation without complex menus or training.

Features and Performance

- Panel Mount Design for Calibration Benches
Ideal for instrument shops, manual loading stations, and control panels where a permanently installed calibrator is required.
- Comprehensive Signal Calibration
Source and measure mA, DC volts, millivolts, RTDs, thermocouples, resistance, and frequency.
-
Milliamp & Voltage Calibration

- Source: 0.00–24.00 mA, 0.00–10.25 VDC, 0.00–80.00 mV
- Measure: up to 24.00 mA, 60.0 VDC, and 80.00 mV

- Temperature Calibration (°C & °F)
Direct temperature calibration with 14 thermocouple types and multiple RTD curves, eliminating manual conversions.
- Built-in Loop Power & HART Support
Internal 24 V loop power supply and 250-ohm resistor simplify transmitter testing and HART hook-ups.
- Flow & Vibration System Testing
Source and read frequency up to 20 kHz, supporting flow meters and vibration sensors.
- Automatic Stepping & Ramping
Configure three preset output points plus auto step and ramp for fast, repeatable calibrations.
- Advanced Diagnostics
Continuity tester with audible tone, MIN/MAX storage, LED indicators for frequency sync and overload detection.
- Clear, Backlit Display
Easy-to-read screen suitable for control rooms and low-light environments.

Why You Should Buy it

- Perfect for fixed calibration benches and control panels
- Replaces multiple single-function calibrators
- Simple operation reduces training time
- Accurate, reliable, and workshop-ready
- Includes NIST calibration certificate and 3-year warranty
