Fluke 750R07 Reference Pressure Module

Overview Fluke 750R07 Reference Pressure Module

Fluke 750R07 Reference Pressure Module is a reference pressure module for compatible Fluke calibrators. It is intended for use with Fluke 740/750 and compatible 720/710 series calibrators. Specified range: 0 to 35 bar with accuracy 0.015% total uncertainty.

Features and Performance

- 0 psi to 500 psi (0 to 35 bar), (0 to 3500 kPa)
- Compatible Media: Type 316 Stainless Steel
- Display pressure readings in any of 10 different pressure units you specify in the calibrator setup
- Rugged urethane molded case protects the module from rough handling and harsh conditions
- Features internal temperature compensation from 32 °F to 122 °F for full-accuracy performance
- Includes NIST-traceable calibration certificate
- Module can be used with any of the Fluke 740, 750 or compatible 720 or 710 series calibrators
- Reference class modules have a 0.015% total uncertainty
- Module has its own serial number to maintain independent traceability
- Includes an adapter set with each module
- 3-year warranty
- NIST-Traceable Calibration Certificate
- Adapter Set with Each Module

Why Choose This Product

This model fits calibration workflows that need a defined pressure range and a module matched to compatible instruments. The compatibility information in the source data points to use with Fluke 740/750 and compatible 720/710 series calibrators. It is relevant when the application specifically calls for 0 to 35 bar.

Product Specifications

Feature Details

Type Reference Pressure Module

Range 0 to 35 bar

Accuracy 0.015% total uncertainty

Compatibility Fluke 740/750 and compatible 720/710 series calibrators
