Fluke 717-1500G Pressure Calibrator

Overview Fluke 717-1500G Pressure Calibrator

Fluke 717-1500G Pressure Calibrator is a pressure calibrator from Fluke. It supports pressure calibration with simultaneous pressure and mA measurement, 24 V loop power, and compatibility with Fluke 700Pxx pressure modules. The source data lists 0-1500 PSI.

Features and Performance

- Measure mA with 0.015% accuracy and 0.001 mA resolution, while sourcing 24V loop power
- Measure pressure to 10,000 psi/700 bar using one of 29 Fluke 700Pxx Pressure Modules
- 1/8 NPT female pressure fitting
- Compatible with non-corrosive Gases and liquids
- Select eleven different engineering units
- Zero, min, max, and hold functions
- Calibrate P/I instruments with simultaneous pressure and current measurement
- Pressure switch test function captures set, reset and Deadband values of a pressure switch

Why Choose This Product

The combination of internal sensor measurement, mA measurement, and loop power makes it relevant for pressure transmitter calibration and related process checks. Compatibility information in the source data includes compatible with Fluke 700Pxx differential, gauge and absolute pressure modules. The supplied package includes Protective Yellow Holster with test lead storage, Instructions Sheet (14 languages), Single 9V alkaline battery, and Test Leads and Alligator Clips.

Product Specifications

Feature Details

Range 0-1500 PSI

Connection 1/8 NPT female pressure fitting

Compatibility Compatible with Fluke 700Pxx differential, gauge and absolute pressure modules

Power Long lasting battery life
